Introduction

LSZH/EPR NSHXAFO rubber cable structure:

Standards:VDE 0250 T. 606; Conductor:tinned copper,fine stranded, class 5; Insulation:rubber (EPR) 3GI3, halogen-free Sheath:FRNC compound HM3; flame retardant:VDE 0482-332-1-2/IEC 60332-1；smoke density:DIN EN 61034/IEC 61034;halogen free：DIN EN 50267/IEC 60754; oil resistant:EN 60811-2-1; maximum temperature at conductor:90 °C; max. operating temperature, fixed:-40 - +70 °C ; temperature, moved/during installation:-25 - +70 °C

Flam retardant LSZH/EPR NSHXAFO rubber cable description:

NSHXAFO is a VDE approved, 1.8/3kV, halogen-free, EPR insulated polymer jacketed single conductor cable. This rubber cable is widely used in public transport and also for general wiring.

NSHXAFO rubber cable is both flame-retardant and oil-resistant and is especially suitable for protection against short circuits in laying and for inherently earth-fault-proof routing in trains and buses. The rubber cable is particularly of use in pipes, conduits, ducts, tubes and closed installation channels.

Flam retardant LSZH/EPR NSHXAFO rubber cable Application range

.Wiring of machines, tools, devices, appliances and control cabinets

.Railway vehicles, buses, switching stations (short-circuit-proof up to 1000 V), power distributors (short-circuit-proof up to 1000 V)

.No direct burial, except of lead-through through fire separations such as sand cups

.In ducts, tubes, pipes, conduits and closed installation channels

.Bundled or for connection of movable part

1. Benefits

.Arrangements made of single-conductor cables NSHXAFö in accordance with VDE 0250 Part 606 with nominal voltage of at least U0/U: 1.8/3 kV can be used for short circuit-proof and short-to-ground-proof installation up to 1000 V in acc. with VDE 0100 Part 520 and VDE 0298 Part 3

2. Design

.Fine copper wire strands

.Core insulation: halogen-free rubber compound type 3GI3, according to DIN VDE 0207-20

.Outer sheath: halogen-free HM3 polymer compound according to DIN VDE 0250-606, in black, other colours available on request

.No outer sheath

3. Approvals

. The “CE” mark is forbidden as the normative nominal voltage U0/U = 1.8/3 kVac falls outside low voltage as defined by the EC Low Voltage Directive 2006/95/EC, which is the standard to which the “CE” mark on most of the cables that we sell refers

4. Product features

.Halogen-free: to protect human life and valuable assets in the event of a fire, through low smoke density and low amount of corrosive gases

.Flame-retardant according to IEC 60332-1-2

LSZH/EPR NSHXAFO rubber cable parameter:

Part number	Conductor cross-section (mm²)	Outer diameter (mm)	Copper index (kg/km)	Weight (kg/km)
3022673	1,5	7	14.4	60
3022674	2,5	7,5	24	70
3022675	4	9	38.4	90
3022676	6	9,5	57.6	120
3022677	10	11	96	180
3022678	16	13	153.6	250
3022679	25	15	240	390
3022680	35	16,5	336	470
3022681	50	18	480	625
3022682	70	20,5	672	880
3022683	95	24	912	1190
3022684	120	26	1152	1430
3022685	150	28	1440	1750
3022686	185	31	1776	2160
3022687	240	34,5	2304	2718
3022688	300	38	2880	3470
