PVC Welding Cable


1. Voltage:450/750V,2.Insulated:PVC,3.Conductor:flexible copper,4.Standard:IEC.

Tel:+86-371-6676-6667 / E-mail:sales@hlcables.com

Introduction

PVC welding cable Structure:
standard:IEC60331,EC60332-1;Conductor:Highly flexible class 6 annealed copper     Insulation: PVC    Voltage Rating: 450/750V      Minimum bending radius: 6 x overall diameter.                            Max operating temperature:70°C on conductor is installed in ordinary environments.       Max temperature in case of short circuit:Max duration 5 seconds. 160°C on conductor
Minimum bending radius: 6 x overall diameter.
Rubber Welding Cable Description:
PVC welding cable can be used for the transmission of high currents from the electric welding machine to the welding tool. It is suitable for flexible use under rough conditions, on assembly lines and conveyor systems, in machine tool and motor car manufacturing, ship building, for manually and automatically operated line and spot welding machines.
The PVC welding cable retains high flexibility even under influence of ozone, light, oxygen, protective gases, oil and petrol. Robust cable structure of these cables makes them resistant to low and high temperature, fire, ozone and radiation, oils, acids, fats and petrols. These cables are also ideal for outside installation in dry, moist and wet areas.
Easy to use inside visible or embedded piping. Direct burial installation or outdoors in wet environments as well as contact with hot parts is not allowed. It must not be subject to thermic radiation.
PVC welding cable is used as leading wire for welding machine and also applied to power or electrical household appliances and a variety of electrical devices and tools with rated voltage Uo / U 100/100V.
Construction:
1 Conductor:   A)Annealed class 5 flexible copper wire     B)Overall diameter of single wire: 0.2mm2   C)NO. of copper wire: 2214
2 Insulation:    A)Double flexible PVC (Blue or Orange)     B)Heat resistant,Oil resistant and flame retardant(Not better than rubber)     C)Thickness of insulation:3.2mm
Technical Data:
1 Max.operating temperature:    A)+70°C (Used as power transmission)       B)+95°C(Used as welding cable)
2 Rated voltage:     A)600V (Used as power transmission)    B)220V (Used as welding cable)
3 Other data:           A)Overall diameter: 17.00mm                    B)Approx weight: 793Kg/Km           C)Conductor structure: 2214/0.2
Rubber Welding Cable Application:
  For welding application,secondary side connection of power sources where heavy duty portable supply in dry wet and oil environment.Such as motors,generators,transformers all kinds of flexible connection are applicable.
PVC welding cable Note:Can be supplied in any size if required

Cable Size

Strands  Number

Stands Size

Average OD  (mm)

Max.Conductor Resistance at 20℃

Norminal Weight

mm²



mm

Min.

Max.

≤Ω/km

kg/km

16

513

0.2

9

11.5

1.21

240

25

798

0.2

10.5

13

0.78

350

35

1121

0.2

11.5

14.5

0.554

450

50

1596

0.2

13.5

17

0.386

625

70

2220

0.2

15.5

19.5

0.272

825

95

3034

0.2

17

22

0.206

1125

120

1702

0.2

19

24

0.161

1380
