Flexible wire cable
1.voltage:300/500V,2.Insulation:Polyvinyl chloride (PVC) 3.copper conductor 4.Standard:IEC60227
Introduction
Flexible wire cable Standards:
International: IEC 60227 China: GB/T 5023-2008 Other standards such as BS,DIN and ICEA upon request
Descriptions:
Single-core non-sheathed cables with flexible conductor for internal wiring for a conductor of 90℃
Code designation: 60227 IEC 08 (International), RV-90 300/500V(China)
Constructions
1.Conductor: Flexible copper conductor, comform to IEC 60228 class 5
2.Insulation: PVC
Flexible wire cable Applications: Used in the switch control, relay and instrumentation panels of power switchgear and for purposes such as internal connectors in rectifier equipment, motor starters and controllers.
Technical data
Rated voltage:300/500V Max. Conductor Temp. in normal use:90℃ Min. Bending Radius: 6 x cable O.D
Parameter:
|
Cross section mm2 |
Construction（mm） |
Weight |
||
|
Copper conductor |
PVC Insulation |
|||
|
Numbers of wire |
Wire Dia. |
Norminal |
cable |
|
|
0.5 |
16 |
0.2 |
0.6 |
9.1 |
|
0.75 |
24 |
0.2 |
0.6 |
12.3 |
|
1 |
32 |
0.2 |
0.6 |
15 |
|
1.5 |
30 |
0.25 |
0.7 |
21.8 |
|
2.5 |
49 |
0.25 |
0.8 |
34 |
|
4 |
56 |
0.3 |
0.8 |
50.8 |
|
6 |
84 |
0.3 |
0.8 |
74.8 |
|
10 |
84 |
0.4 |
1 |
129.8 |
|
16 |
126 |
0.4 |
1 |
172 |
|
25 |
196 |
0.4 |
1.2 |
265.6 |
|
35 |
276 |
0.4 |
1.2 |
361.7 |
|
50 |
396 |
0.4 |
1.4 |
516.5 |
|
70 |
360 |
0.5 |
1.4 |
714.9 |
|
95 |
475 |
0.5 |
1.6 |
944.9 |
|
120 |
608 |
0.5 |
1.6 |
1185.3 |
|
150 |
765 |
0.5 |
1.8 |
1492.3 |
|
185 |
925 |
0.5 |
2 |
1809.3 |
|
240 |
1221 |
0.5 |
2.2 |
2374.3 |
