ACSR/AW Conductor

ACSR conductor Aluminum conductor aluminum clad steel reinforced is widely used in the overhead power distribution system

Introduction Interrelated Quotation

Tel:+86-371-6676-6667 / E-mail:sales@hlcables.com

Introduction

ACSR/AW-aluminum clad steel reinforced conductor description:

Standards:IEC 60889:1987,Other standards such as BS,DIN and ICEA upon request

Applications: Conductor (ACSR and Rare earth ACSR) have been widely used in power transmission lines with various voltage levels, because they have such good characteristics as simple structure, convenient installation and maintenance, low cost large transmission capacity. And they are also suitable for laying across rivers valleys and the places where special geographical features exist.

Constructions:

Conductor: Aluminum Reinforced: Steel core"aluminized" aluminum coated (AZ); or aluminum-clad (AW)

Brief Description:

ACSR conductor consists of a solid or stranded steel core surrounded by strands of aluminium (E.C. GRADE).

ACSR Conductor may be manufactured for having a wide range of tensile strength as per requirement. The principal advantage of these conductors are high tensile strength and light weight with longer spans as well as with lesser supports. Due to the greater diameter of ACS Conductor a much higher corona limit can be obtained causing big advantages on high as well as extra high voltage overhead lines.

Types:

1. The steel core can be changed to high-strength or extra-high strength, which can enhance the tensile strength of the wire.

2. ACSR shall have three cases of grease applied as protection against corrosion:

Case 1: steel core only greased;

Case 2: all the conductor is greased except the outer layer;

Case 3: all the conductor is greased except the outer surface of the wires in the outer layer.

parameter:

S/N.	Code Name	Construction	S/N.	Code Name
1	MOLE	6/1/1.50	12	RACCOAN
2	SQUIRREL	6/1/2.11	13	OTTER
3	GOPHER	6/1/2.36	14	CAT
4	WEASEL	6/1/2.59	15	HARE
5	FOX	6/1/2.79	16	DOG
6	FERRET	6/1/3.00	17	HYENA
7	RABBIT	6/1/3.35	18	LEOPARD
8	MINK	6/1/3.66	19	COYOTE
9	SKUNK	12/7/2.59	20	TIGER
10	BEAVER	6/1/3.99	21	WOLF
11	HORSE	12/7/2.79	22	LYNX
